PUF Sheet

A PUF sheet (also known as a PUF insulation sheet or PUF insulation blanket) is a layered insulation material engineered so that its multiple layers work in combination to resist heat transfer, delivering reliable thermal insulation across a wide range of applications.

Parameter Specification
Density 36 to 40 kg/m³
Thickness 15 – 300 mm
Dimensions 1 m L x 0.5 m W
Temperature Range -40°C to 110°C
Thermal Conductivity 0.021 W/m·K @ 10°C
Compressive Strength 205 kN/m²
Water Absorption 0.5% by volume
Water Vapor Permeability 5.5 max (ng/Pa·s·m)
Suitable For

Applications

Residential Buildings
used in walls, roofs, and floors to improve energy efficiency and thermal comfort
Commercial Buildings
used in offices, malls, and warehouses to regulate indoor temperatures and cut energy use
Industrial Settings
insulates equipment, pipes, tanks, and infrastructure to maintain process temperatures and conserve energy
Automotive Industry
insulates vehicle interiors, engine compartments, and other components for cabin comfort and efficiency
HVAC Systems
prevents heat loss or gain through ducts and pipes
Cold Storage
maintains controlled temperatures and reduces energy consumption
Agricultural Applications
used in greenhouses to regulate temperature for optimal growing conditions
Electronic Devices
insulates devices and components, protecting them from temperature fluctuations
Product Benefits

Advantages

High Thermal Resistance

effectively resists heat transfer, maintaining a stable temperature differential

Lightweight

relatively light compared to other insulation materials, easier to handle and install

Flexible and Easy to Install

can be cut, shaped, and installed on curved or irregular surfaces

Low Thermal Conductivity

minimizes heat flow, conserving energy and reducing heat loss or gain

Non-toxic and Environmentally Friendly

often manufactured without harmful chemicals

Non-toxic and Environmentally Friendly

often manufactured without harmful chemicals

Moisture Resistance

helps prevent moisture buildup and potential mold growth

Durable

designed for long-lasting insulation performance
